PRIDE MATRIX TAPERED 24" FORK
With its glossy/matte finish, the new Pride Matrix fork boasts a sleek and elegant design. It is composed of two distinct parts. The fork legs are made from 100% Torray® HM carbon, combined with an internal PMI polymer structure, which increases overall stiffness and strength. Different types of carbon fibers are used based on their specific properties to best manage various loads in areas where they occur such as lateral loads, torsion, and impacts.
The steerer tube is made from 7075-T6 aluminum, a high-strength alloy known for its durability and resistance. This feature ensures not only strong structural integrity but also enhanced longevity.
Complies with EN 16054 standard.
SPECIFICATIONS
-
Material : Torray Carbon / 7075 Aluminum
-
Wheel size : 24"
-
Axle : 20mm (not included)
-
Steerer diameter : Tapered 1"-1/8 to 1.5"
-
Steerer length : 165mm
-
Fork height : 357mm
-
Offset : 30mm
-
Compression bolt : M22x1.5mm
-
Compression bolt length : 20mm
-
Weight : 639g (with compression bolt)
TORQUE SETTINGS
-
IMPORTANT : Always use a torque wrench
-
Compression bolt torque : 8 Nm (Max)
-
Stem bolt torque : 13 Nm (Max)
-
Hub axle torque : 8 Nm (Max)
